| Function | Cooling |
| BTU/hr | 12000 |
| Rated Voltage | 230V ~ 50Hz |
| Rated Input Power (W) | 1260 |
| Rated Current (A) | 5.6 |
| Cooling Capacity (W) | 3517 |
| EER | 2.8 |
| Compressor Type | Rotary (Fixed Speed) |
| Refrigerant Type | R-410a |
| Refrigerant Amount (Kg) | 0.7 |
| Operating Range (Ambient Temperature) | 20˚C to 43˚C |
| Evaporator Fin Type | Louvered Fin |
| Condenser Type | Copper Tube Condenser |
| Condenser Fin Type | Slit Fin |
| Maximum Pipe Length | 10m |
| Display Type | LCD |
| Operation/Control | Via IR (Infrared Ray) |
| Child Lock | Yes |
| Temperature Unit Change | Yes (16°C to 31°C) |
| Auto UP-Down Swing | Yes |
| Auto Left-Right Swing | Yes |
| Indoor Dimensions (mm) [L×W×H] | Unit: 832 x 296 x 210 |
| Packing: 910 x 365 x 285 | |
| Outdoor Dimensions (mm) [L×W×H] | Unit: 721 x 320 x 552 |
| Packing: 825 x 365 x 630 | |
| Net Weight (Indoor) (Kg) | 10.7 ± 0.5 |
| Gross Weight (Indoor) (Kg) | 12.85 ± 0.5 |
| Net Weight (Outdoor) (Kg) | 26.10 ± 1 |
| Gross Weight (outdoor) (Kg) | 29.90 ± 1 |
| Warranty Information | |
| For Residential Usage | Compressor Warranty: 5 Years |
| Spare Parts Support: 3 Years | |
| After Sales Service: 1 Year (Free) | |
| For Commercial Usage | Compressor Warranty: 5 Years |
| Spare Parts Support: 2 Years | |
| After Sales Service: 1 Year (Free) | |
